新たに開発された機能、設計や最適化の方法など、KISSsoftについてもっと知ってください。そして様々な計算例を職場で直接ご覧になってください。弊社のインタラクティブなウェブデモは無償です - たった45分で、KISSsoftの様々なアプリケーションを体験いただけます。

弊社のインタラクティブなウェブデモでは、KISSsoft の計算プログラムをめぐる様々なテーマについて情報が提供されています。たとえウェブデモを見逃したとしても、1日後にはその録画が配信されます。

The loaded tooth contact analysis (LTCA) is crucial in understanding the deformation of gears and its impact on various factors such as noise generation, contact patterns, contact shocks, and torque variations. With the contact analysis feature in KISSsoft®, users can calculate tooth contact under specific torque and speed levels, thereby assessing the performance of gears and gearboxes. LTCA forms the foundation for a robust micro-geometric gear design, including lead and profile modifications. In this web-demo, you will gain insights into parallel axis and coaxial gearboxes, focusing on the following aspects:

• Loaded tooth contact analysis
• Stiffness calculation for teeth, shafts, bearings, housing, planet carrier, and gear body
• Analysis of system deformation and its impact on gear contact patterns
• Designing lead modifications for optimal strength and contact patterns
• Designing profile modifications for optimal behaviour in terms of power, NVH (noise, vibration, and harshness), efficiency, and contact temperature
• Optimization of modifications for duty cycles

The gear body of a gear is the main determinant of its stiffness. It is thus becoming clear in industry that designing a high-performance gear or drivetrain is barely possible without an accurate consideration of the gear body stiffness. KISSsoft® addresses this challenge by combining the FE method with analytical models. Our Software Developer, Dipl. Eng., MSc Theofanis Tsiantas, will show you:

• How to accurately calculate the stiffness matrix of a gear body with KISSsoft®
• Advanced modeling possibilities for gear bodies
• What is the effect of the gear body stiffness on different KISSsoft® calculations
• Future directions on extending the current modeling capabilities of gear bodies in KISSsoft®


Take 60 minutes to learn more about the functions of KISSsoft®!

Learn more in the web demo about how the enhancements in KISSsoft®Release 2023 will make your gear and shaft design more efficient, how the effect of the gear body geometry is and the tool design process can be optimized. The following points will be presented:

• Gear body geometry including rim
• Gear mesh and bearing frequencies
• Comparison of tools
• Data exchange with GDE 3.2 and REXS 1.4
• FKM shaft rating with rainflow matrix

Please take 60 minutes time for this web demo.

Low noise and minimum vibrations are key to quiet and efficient operation. Profound NVH analysis is the answer to optimize noise and acoustics in conjunction with reduced vibration behavior of vehicles and vehicle components such as electric drive train systems.

KISSsoft® offers the user the possibility to perform an NVH assessment of gearboxes. The calculation of the noise excitation within the drive train is based on the forced vibration, which leads to the determination of the transient bearing loads.

These results are then transferred to the multi-body simulation program RecurDyn and applied to the flexible housing structure. This allows the system response of the housing as airborne sound to be viewed in steady state. In addition to the usual outputs, the engineer also has the radiated power ERP (Equivalent Radiation Power) at all points of the enclosure at his disposal.

Noise emissions from gear units in electric vehicles are a major problem. In practice, the profile form deviation is controlled strictly. For this reason, it is important to find a method that can be used to estimate the influence of the manufacturing accuracy. The application of this method to some modern gear units will be presented in our web demo:

• Application in the calculation
• Variation of the waviness
• Application to an industrial gearbox
• Application to an EV gearbox

Learn more about how the enhancements in KISSsoft® Release 2022 will make your gear design more efficient and refined. We are also excited to show KISSsoft® in a modernized look. Further topics:

• Influence of flank waviness on transmission error
• Tooth root fatigue strength from time series
• Bearing contact stress with modified raceways
• Bearing inner geometry from Schaeffler and Timken
• Optimized bolt module interface
• and many more

Please take 60 minutes time for this web demo.

The three-day event featured one topic per day addressing the specific requirements and challenges of e-drive transmissions, with particular attention to minimizing gear noise.

The first day was dedicated to the design of e-drive transmissions and looked at several aspects of gear design in an EV system environment. High rpm’s, reversal of load direction, low vibration excitation, high contact ratios, increased risk of scuffing, deformed housings - the design, optimization and service life calculation of gears for e-drives is a world of its own.

We will present various applications and provide an overview of the functionalities for manufacturing in KISSsoft®:

• Design tools with protuberance, semi-toppings and modified pressure angle
• Calculate tooth thickness dimensions for span widths, measurement over balls and graphical evaluation
• Collision check for power skiving and honing
• Evaluate grinding notches and tooth root stresses
• Calculate noise excitation from manufacturing simulation or measured gears
• Manufacture non-evolute gears such as park lock gears or sprocket gears

Please take 60 minutes time for this web demo.

Our web demo provides you with an overview of various features in the KISSsoft® bearing calculation:

• Overview of calculation methods for rolling bearings in KISSsoft®

• Application and advantages of calculation according to ISO/TS 16281
• SKF Cloud Service: Accurate rolling bearing stiffness and life directly via SKF service

We would like to show you the numerous new features in KISSsoft® Release 2021 for gears, shafts, bearings and other machine elements. Also the news in drivetrain and system calculation will be shown.

Have a look at these new features:

• Bearing calculation with inner geometry in the „SKF Cloud“
• Collision check during honing and power-skiving
• Import possibility of cylindrical gear flank measurement grid
• System reliability at a glance with AGMA 6006-B20
• Define and compare variants of gear modifications

One of the key aspects in modern software development is to give end users sufficient freedom to adapt their working environment to current market requirements. In KISSsoft, various options are available for personalizing the software handling and tailoring it to your own needs.

Plastic gears offer the engineer more freedom to influence the tooth form, since they are usually manufactured using injection molding instead of hobbing processes. In this web demo, we will show you the options in KISSsoft for designing plastic gears.

Language: English

This web demo will cover the innovations in ISO 6336, the most important standard for strength calculation of cylindrical gears. Our experts – Dr. Eng. Ulrich Kissling, MSc. Eng. Ilja Tsikur und Grad. Eng. Hanspeter Dinner – will explain the theoretical background and show you the effects of the changes using examples from wind power, EV gearboxes etc.

In 50 minutes, Eng. Ilja Tsikur will show you how to design and optimize gears for E-Mobility applications in KISSsoft. Followig topics are covered: building up the kinematic model, sizing of gear macro-geometry and of protuberance cutter profile to eliminate grinding notch, loaded tooth contact analysis, sizing of gear micro-geometry for low noise excitation and more.

We would like to show you the numerous new features in KISSsoft calculation program for gears, shafts, bearings and other machine elements. Get an overview of the new features in the KISSsoft Release 2019 during this 45 minutes demo.
